Adding Custom JavaScript to the Map

3 examples of how you can enhance the functionality of the interactive map for WordPress.

As of version 2.9.9.6, our WordPress map plugins support a new advanced feature. Now you can add custom JavaScript code to the map. This code executes after the map is drawn and has access to most of the map’s properties. Thanks to this feature you can implement all kinds of interactive behavior previously impossible or hard to do.

Enhancing capabilities of Map plugins for WordPress

Our plugins are well-acclaimed for their extremely simple interface, so even a novice WordPress user can easily configure and embed an interactive map on his or her WordPress website. All settings are visual and do not require any coding. Settings cover colors, tooltips, adding points, grouping countries into regions, and other possibilities.

In this post https://www.fla-shop.com/blog/5-types-of-interaction-in-plugin-us-map-for-wordpress/ you can find some examples of map interaction that even a complete rookie can implement.
At the same time, our maps have JavaScript API, so experienced developers can implement complex and non-standard usage scenarios for plugins. And now this gets even simpler thanks to the custom JavaScript code field already added into the plugin settings.

The following update refers to the following products: US Map for WP, World countries Map for WP, as well as all single-level map plugins.

How custom JavaScript works

Custom JavaScript code is executed when the map is drawn for the first time. Any further redraws of the map do not trigger the execution. However, if you have multiple instances of the map on the same page, each one will execute its own custom JS code.

In the script, you can use any JS code, such as: execute standard or custom functions, read and write values of variables, parse the HTML document and whatever else. In addition, in the script you have access to the following variables:

map – an instance of the map that provides access to public methods of the map class. This includes callback handlers that allow you to perform certain actions in response to certain events (see below).

You can find the complete list of methods available to you here.

containerId – this variable holds the HTML id of the container the map is placed to.

Example:

map.on('click', function (event, sid, map) {
   var name = map.fetchStateAttr(sid, 'name');
   console.log('Clicked state is: ' + name);
});

How to add custom JavaScript to the map

Open map settings and switch to the ‘Tools’ tab. Scroll down to the Custom JavaScript section:
Custom JavaScript on Map plugin

You can insert custom JavaScript code in the corresponding textbox. Click the ‘Save changes’ button.

Here is what the above example code does. It fetches a name of the state on the map that a user has clicked and prints that name to the console.

What can you do with custom JavaScript

Since you have access to most of the map object methods as well as to the HTML of the page, you can do almost anything. Let’s review some basic functions provided by the map object:

Callback functions

By using the FlaMap.on method you can assign a callback function to certain events including: on click, on double click, on mouse move, on mouse in, on mouse out, on mouse button down and on mouse button up.
The callback function receives the original event that triggered the callback; the state id corresponding to the event (for example, if the event is a click, the function receives the id of the clicked state); the map object.

Map state manipulation

The map object provides a number of ways to view or modify various state settings: name, color, label, is a state shown or hidden, and is a state enabled or not. You can also modify the URL assigned to a specific state.

Points manipulation

Map points are used to mark various objects on the map: headquarters, dealership network sites, local offices, and so on. Using custom JavaScript you can track click on map points, as well as change their parameters: label, color, size, coordinates, assigned URL.

Map drawing and overall appearance

You can adjust general settings of the map and initiate redrawing using the map.reloadMap() method.

Please refer to the documentation on the complete list and description of FlaMap methods.

Examples of use

Auto-fill forms

A map combined with a form can simplify filling in the data for a user.
For example, if a form has such fields as State or Country, then normally a user would have to manually type or select these values from the dropdown. With a map enhanced with custom JS code, you can simplify this down to just one click on the map.

What you need is to write a callback function and pass it to the FlaMap.on method. In the callback function, you fetch the name of the clicked state/country and insert the corresponding state/country values to the form.

Select multiple states

If you need to give your visitor a possibility to select multiple states, using custom JavaScript can help. We have reviewed a similar example for non-WordPress maps here: https://www.fla-shop.com/howto/interacting-with-maps-via-checkboxes/

Tracking clicks on states in Google Analytics

A common use case of our map plugins is displaying a dealership map for the given country or state. When a state or a country is clicked on the map, the corresponding contact information displays side-by-side with the map. And now, if you want to know how often this or that state or country is clicked and see this info in Google Analytics, you can use custom JavaScript to integrate the map to GA and therefore see the map click data.

Specifically, you need to invoke Google Analytics’ scripts (analytics.js, gtag.js etc) from your custom JS code.

Conclusion

As you see, custom JavaScript added to the interactive map can greatly enhance its basic functionality. Enjoy!
